small,with a new vision

Total weight is 248g,with 2-axis gimbal,easy to carry,easy to shoot!

weight
248g
style
simple

One key take off/land

one key take off,humanized design,more intelligent flight

One key return

Only one button,Obtain will return automatically,make everything simple!

Flight time

Dream can fly 15mins,control distance is about 800m
take you to feel different view

Precision hover

GPS+GLONASS syetem,make Dream stable.

Optical flow system,make Dream hover indoor.

With advanced optical flow algorithm
it has better adaptability to all kinds of ground textures

20km/hFlight Speed

2m/sRising Speed

1.5m/sDescending speed

2-axis gimbal

Pitch angle:-90°~0°

The precise damping layout,
to improve the gimbal stability
  • 720P real time live show,1080P high quality video

    Moving your fingers, close to the distance between you and the world

  • 720P real time live show,1080P high quality video

    Moving your fingers, close to the distance between you and the world

  • 720P real time live show,1080P high quality video

    Moving your fingers, close to the distance between you and the world

  • 720P real time live show,1080P high quality video

    Moving your fingers, close to the distance between you and the world

  • 720P real time live show,1080P high quality video

    Moving your fingers, close to the distance between you and the world

720P real time live show,1080P high quality video

Moving your fingers, close to the distance between you and the world

Fly around mode

Set flying radius to help you shoot extraordinary pictures

Follow me mode

Built-in GPS Module,it will follow wherever you go

waypoint function

Planning route,you can make Dream fly as your command!

Low battery return

first low battery warning
Dream will fly back automatically.

Low battery protection

Second low battery warning
Dream will land at current location

Losing control protection

When Dream losing signal
It will automatically fly back and land safely.

Learn more about Dream

Dream

  • Size:
  • 148 X 145 X 60 mm(L X W X H )
  • Wheelbase:
  • 175mm
  • Weight (Battery & Propellers Included):
  • 248g
  • Max Ascent Speed:
  • :2m/s
  • Max Descent Speed:
  • 1.5m/s
  • Max Speed:
  • 20km/h
  • Max Service Ceiling Above Sea Level:
  • 3000m
  • Max Flight Time:
  • 15mins
  • Max Total Travel Distance:
  • 3km
  • Operating Temperature Range:
  • 0~40°
  • Satellite Positioning Systems:
  • GPS/GLONASS
  • Hover Accuracy Range:
  • Vertical: +/- 0.5 m Horizontal:+/- 0.5 m (when Optical flow is active);+/- 1.0m
  • Operating Frequency:
  • FCC:5.150-5.250GHZ; CE:5.150-5.250GHz
  • Transmitter Power (EIRP):
  • 5.2GHz FCC:<=23dBm

Optical flow system

  • Optical flow system:
  • yes
  • Operating Environment:
  • Surface with clear pattern and adequate lighting (lux > 15)
  • Velocity Range:
  • ≤1.5 m/s at 6.6 ft (2 m) above ground
  • Altitude Range:
  • 0.5~5m

Gimbal

  • Controllable Range:
  • Pitch:-90°~0°
  • Stabilization:
  • 2-axis(pitch,roll)

Camera

  • Sensor:
  • 1/2.7"CMOS
  • Lens:
  • FOV 110° 42 mm(35 mm format equivalent)
  • ISO Range:
  • video:100 - 3200 photo:100 - 1600
  • Image Size:
  • 2560*1440
  • Video Recording Resolution:
  • FHD:1920*1080
  • Supported File Systems:
  • FAT32(<=32GB)
  • Photo:
  • JPEG
  • Video:
  • MP4
  • Supported SD Cards:
  • Micro SD™ Max capacity: 32GB. Class 10 or UHS-1 rating required
  • Operating Temperature Range:
  • 0~40°

Battery

  • Capacity:
  • 1000 mAh
  • Voltage:
  • 11.4V
  • Battery Type:
  • LiPo 3S
  • Energy:
  • 10.83 Wh
  • Net Weight:
  • about 72g
  • Charging Temperature Range:
  • 5~40°
  • Max power:
  • 15W

Live view

  • Mobile App:
  • C-Fly
  • Live View Quality:
  • 720p
  • FPV transmission distance:
  • 800m
  • Required Operating Systems:
  • iOS 9.0 or later Android 4.4 or later

Charger

  • Voltage:
  • 12.6V
  • Rated Power:
  • 18W

WiFi

  • Operating Frequency:
  • 5G
  • Max Transmission Distance:
  • Horizontal:200m,Vertical:150m
  • Max Speed:
  • 20 km/h
  • Max Ascent Speed:
  • 2 m/s
  • Max Descent Speed:
  • 1 m/s

Remote Controller(Optional)

  • Operating Frequency:
  • 5GHz
  • Max Transmission Distance:
  • 800m
  • Operating Temperature Range:
  • 0~40°
  • Transmitter Power (EIRP):
  • FCC:<=26dBm; CE:<=20dBm; SRRC:<=20dBm
  • Operating Current/Voltage:
  • 1.5A@3.7V
  • Supported Mobile Device Size:
  • Thickness Supported:6.5-8.5mm Max length: 80mm
  • Port types:
  • Micro USB
  • Charge:
  • USB port
  • Max charging power:
  • 5w

Battery of Remote Controller(Optional)

  • Capacity:
  • 2600mAh
  • Voltage:
  • 3.7v
  • Battery Type:
  • LiPo 18650 1S
  • Energy:
  • 9.62Wh
  • Net Weight:
  • about 60g
  • Operating Temperature Range:
  • 5~40°
