Foldable Drone,Easy to carry

The Size of foldable Obtain:220 x 110 x 98 mm,whole weight is 825g(with battery),very convenient for you to carry Obtain to close nature.

Unfoldable Obtain

small size with powerful energy,brushless motor,light propeller,to experience fun flight

One key take off/land

one key take off,humanized design,more intelligent flight

One key return

Only one button,Obtain will return automatically,make everythinh simple!

Flight time

Obtain can fly 25mins,control distance is about 1500m,the longer time Obtain can fly, the wider vision you can ever get!

Precision hover

GPS+GLONASS syetem,make Obtain stable

34km/hFlight Speed

2.5m/sRising Speed

1.5m/sDescending speed

3-axis gimbal

The precise damping layout,is combined with the new generation control algorithm to improve the gimbal stability

  • 720P real time live show,1080P high quality video

    Moving your fingers, close to the distance between you and the world

  • 720P real time live show,1080P high quality video

    Moving your fingers, close to the distance between you and the world

  • 720P real time live show,1080P high quality video

    Moving your fingers, close to the distance between you and the world

  • 720P real time live show,1080P high quality video

    Moving your fingers, close to the distance between you and the world

720P real time live show,1080P high quality video

Moving your fingers, close to the distance between you and the world

Fly around mode

Set flying radius to help you shoot extraordinary pictures.

Follow me mode

Built-in GPS Module,it will follow wherever you go.

waypoint function

Planning route,you can make Obtain fly as your command

Low battery return

first low battery warning
Obtain will fly back automatically.

Low battery protection

Second low battery warning
Obtain will land at cuttent loaction

Losing control protection

When Obtain losing signal,
It will automatically fly back and land safely.

multiple functions

leran more about Obtain

  • way point function
  • one key take off
  • follow me
  • one key return
  • fly around mode
  • flight time
    25mins
  • Real time live show
  • 1080P video
  • lose control protection
  • Low battery protection

Obtain parameters

  • Folded Size:
  • 220*110*98mm(L X W X H)
  • Wheelbase:
  • 350mm
  • Weight (Battery & Propellers Included):
  • 825g
  • Max Ascent Speed:
  • in Sport mode :2m/s
  • Max Descent Speed:
  • 1.5m/s
  • Max Speed:
  • 35km/h
  • Max Service Ceiling Above Sea Level:
  • 4000m
  • Max Flight Time:
  • 25mins(no wind)
  • Max Total Travel Distance :
  • 5km
  • Operating Temperature Range:
  • 0~40°
  • Satellite Positioning Systems:
  • GPS/GLONASS
  • Hover Accuracy Range:
  • Vertical:+/-0.5m;Horizontal:+/-1m
  • Operating Frequency:
  • FCC:5.150-5.250GHZ; CE:5.150-5.250GHz
  • Transmitter Power(EIRP):
  • 5.2GHz FCC:<=23dBm

Gimbal

  • Controllable Range:
  • Pitch:-90~0°
  • Stabilization:
  • 3-axis(pitch,roll,course)

Camera

  • Sensor:
  • 1/2.7"CMOS
  • lens:
  • FOV 70° 25 mm(35 mm format equivalent)
  • ISO Range:
  • video:100 - 3200 photo:100 - 1600
  • Image Size:
  • 2560*1440
  • Video Recording Resolution:
  • FHD:1920*1080 30fps
  • Supported File Systems:
  • FAT32(<=32GB)
  • Photo:
  • JPEG
  • Video:
  • MP4
  • Supported SD Cards:
  • Micro SD™ Max capacity: 32GB. Class 10 or UHS-1 rating required
  • Operating Temperature Range:
  • 0~40°

Battery of Obtain

  • Capacity:
  • 3850 mAh
  • Voltage:
  • 11.1V
  • Battery Type:
  • LiPo 3S
  • Energy:
  • 42.735 Wh
  • Net Weight:
  • about 250g
  • Charging Temperature Range:
  • 5~40°
  • Max power:
  • 50W

APP / Live view

  • Mobile App:
  • C-Fly
  • Live View Quality:
  • 720p
  • Live View Distance:
  • 1000m
  • Required Operating Systems:
  • iOS 9.0 or later Android 4.4 or later

Charger

  • Voltage:
  • 12.6V
  • Rated Power:
  • 50W

WI-FI

  • Operating Frequency:
  • 5G
  • Max Transmission Distance:
  • Horizontal:300m,Vertical:120m(Unobstructed, free of interference)
  • Max Speed:
  • 30 km/h
  • Max Ascent Speed:
  • 2 m/s
  • Max Descent Speed:
  • 1 m/s

Remote Controller

  • Operating Frequency:
  • 5GHz
  • Max Transmission Distance:
  • FCC:1200m; CE:1000m
  • Operating Temperature Range:
  • 0~40°
  • Transmitter Power (EIRP):
  • FCC:<=26dBm; CE:<=20dBm; SRRC:<=20dBm
  • Operating Current/Voltage:
  • 1.5A@3.7V
  • Supported Mobile Device Size:
  • Thickness Supported:6.5-8.5mm Max length: 80mm
  • Port types:
  • Micro USB
  • Charge:
  • USB
  • Max charging power:
  • 5w

Battery of Remote Controller

  • Capacity:
  • 2600mAh
  • Voltage:
  • 3.7v
  • Battery Type:
  • LiPo 18650 1S
  • Energy:
  • 9.62Wh
  • Net Weight:
  • about 60g
  • Operating Temperature Range:
  • 5~40°
